The Steel Mill Dust-proof Conveyor Shield Hood is a protective cover designed for belt conveyors operating in dust-generating steel mill environments. Installed above the conveyor, it creates a physical barrier around the material-carrying area to help limit dust dispersion and reduce direct exposure of the conveyor belt and transported material to the surrounding environment.
The conveyor shield hood is made of colorized galvanized steel plate and is available in models from YDT5 to YDT20, matching conveyor belt widths from 500 mm to 2000 mm. Depending on the selected model, the plate thickness ranges from 0.5 mm to 1.0 mm.
Fixed and openable conveyor cover sections can be arranged together so that the conveying line remains protected while inspection and maintenance positions stay accessible. The effective length of each conveyor cover section is 900 mm.
Different opening widths, heights and radii are available to match the conveyor belt width and installation space. The listed dimensions are reference values, and the conveyor shield hood can be designed and manufactured according to specific project requirements.
The conveyor hood is manufactured from colorized galvanized steel plate. This material provides a practical protective surface for conveyor lines used in dusty industrial environments while maintaining a neat and consistent appearance.
The formed corrugated profile improves the rigidity of the steel plate and helps the cover maintain its shape during installation and operation. The arched structure also creates sufficient internal clearance above the conveyor belt.
Nine standard configurations are available for conveyor belt widths of:
500 mm
650 mm
800 mm
1000 mm
1200 mm
1400 mm
1600 mm
1800 mm
2000 mm
Each model has a corresponding opening width, height and radius to support accurate selection.
Plate thickness increases according to the size of the conveyor cover:
0.5 mm: YDT5, YDT6 and YDT8
0.6 mm: YDT10 and YDT12
0.8 mm: YDT14 and YDT16
1.0 mm: YDT18 and YDT20
The conveyor shielding system can include both fixed and openable cover sections. Fixed sections provide continuous coverage, while openable sections can be positioned at suitable inspection or maintenance points.
Each conveyor cover has an effective length of 900 mm. The modular section design makes it easier to calculate the required quantity according to the total length of the conveyor line.
The shield hood covers the upper part of the conveyor and helps contain dust around the material-conveying area. This is particularly useful for steel mill conveyor lines handling dust-generating bulk materials.
By separating the conveyor from the surrounding environment, the hood helps reduce direct exposure of the belt, conveyed material and upper conveyor components to airborne dust and external contamination.
Containing dust closer to the conveyor can help reduce dust accumulation around the conveying line and simplify routine cleaning and housekeeping.
Models are available for belt widths from 500 mm to 2000 mm, allowing the cover dimensions to be matched more closely to different conveyor specifications.
Openable cover sections can be installed together with fixed sections at selected positions. This arrangement allows operators to access the conveyor for inspection without removing an extended section of the protective hood.
The 900 mm effective section length and clearly defined model dimensions make it easier to estimate the number of cover sections required for a conveyor line.
Where the standard dimensions do not match the conveyor structure or site clearance, the cover can be designed and manufactured according to the actual project requirements.
Model | Belt Width | Thickness | Material | Opening width | Height | Radius |
YDT5 | 500mm | 0.5mm | colorized galvanized steel plate | 846 | 573mm | 423mm |
YDT6 | 650mm | 0.5mm | 996 | 648 | 498 | |
YDT8 | 800mm | 0.5mm | 1196 | 748 | 598 | |
YDT10 | 1000mm | 0.6mm | 1396 | 848 | 698 | |
YDT12 | 1200mm | 0.6mm | 1606 | 953 | 803 | |
YDT14 | 1400mm | 0.8mm | 1856 | 1078 | 928 | |
YDT16 | 1600mm | 0.8mm | 2056 | 1173 | 1028 | |
YDT18 | 1800mm | 1mm | 2300 | 1280 | 1150 | |
YDT20 | 2000mm | 1mm | 2546 | 1423 | 1273 | |
Remark: During installation,should install the opeanable conveyor cover on the two fixed type conveyor covers near it,the effective length of each conveyor cover is 900mm. | ||||||
Note: The listed parameters are for reference. PK Machinery can design and manufacture the conveyor shield hood according to the actual conveyor dimensions and project requirements.
The standard models are designed for belt widths of 500, 650, 800, 1000, 1200, 1400, 1600, 1800 and 2000 mm. Each belt width corresponds to a specific opening width, hood height and radius.
The listed standard models are manufactured from colorized galvanized steel plate. The plate thickness ranges from 0.5 mm to 1.0 mm, depending on the selected model.
Start with the actual conveyor belt width, then compare the corresponding opening width, height and radius with the conveyor frame and available installation space. Site drawings or conveyor dimensions should be checked before confirming the model.
The effective length of each fixed or openable conveyor cover section is 900 mm. The approximate number of sections can therefore be calculated according to the total conveyor length and required access-point arrangement.
Yes. Openable conveyor cover sections can be arranged together with fixed sections at inspection or maintenance positions. When installing an openable section, it should be used with the two adjacent fixed cover sections.
Yes. The dimensions in the technical table are reference values. PK Machinery can design and manufacture the conveyor shield hood according to the actual conveyor dimensions and project requirements.
To support model selection and quantity calculation, please provide:
Conveyor belt width
Total length requiring coverage
Conveyor layout or drawings
Available installation clearance
Required positions for openable sections
Any project-specific dimensional requirements
